3. Exploded Assembly Parts List
Item Quantity Part Name Description
1 3 Plastic dowel Anchor ( 6.0mm)
2 2 Machine screw UNC #8-32 (L=8mm)
3 1 Plate GI 1.6t
4 1 Mount base PF 1”, Aluminium
5 3 Srew M6, L = 35.0mm
6 1 Pipe (90° angle type) PF 1”, Aluminium
7 1 Pipe (straight) PF 1”, Aluminium
8 1 Housing PF 1”, Aluminium
9 1 Gasket 1 for WDDG-1 Housing
10
1 Gasket 2 for Minitrax camera
11 4 Torx screw T-20 (M6 x 20.0)
12 2 Set screw M5 x 5.0mm
13
1 Seal tape Teflon
14
3 Machine screw M6 x 12.0mm
15
1 Special screw for WDDG-1 / Minitrax camera
16
1 Torx wrench T-20
17
1 L-wrench 5mm
