Eneo EDMC-142 - Page 87

87
Cable mounting
Wall
Wall
cable
cable
plate
mount base
plate
mount base
WDDG-1 Minitrax
9
10
Gaskets
Cable passing through the wall Cable on the wall (remove the conduit
knockout for cable passing through)
Fit the srew holes of vandal dome housing into the screw
holes of housing (6) and screw up the M6 torx screws.
Screw up the special screw (15) before install the vandal
proof dome housing.
