Note 3: Charger is acting as a power supply with selected constant output voltage and
preset maximum output current.
NOTE: The equalisation function although included in the ePOWER DC2DC will rarely be
used. To activate the battery bank must be in oat, and manually activated. A typical drive
will not be long enough for the DC2DC function to complete the process. The MPPT Solar
function may provide enough time for Equalisation, but the best recommendation will be
an AC powered battery charger.
Battery Bank Size Recommendation
The battery charging current rating is based on the battery size. The battery bank should
meet the minimum Ah rating as shown. If a smaller size battery bank is used, set the current
rating to a lower value to match with the battery bank size. Normally, the minimum battery
bank capacity is based on a C5 rating of the battery for charging.
EN3DC30
Current Setting 5A 10A 20A 30A
Battery Capacity Min 25Ah Min 50Ah Min 100Ah Min 150Ah
EN3DC30 (Current Setting)
Bulk 30A 20A 10A 5A
ABS-Float 1.5A/ 3A/ 6A 1.0A / 2A / 4A 0.5A/ 1A/ 2A 0.3A/ 0.5A/ 1A
Note: Use the above table to set the Bulk and its related Absorption (ABS) to Float Charge Current.
Unit Setting for Lithium Type Battery (Voltage and Current):
Lithium Voltage Setting : 13.9 – 14.4 (0.1V Step) - EN3DC30 (Current Setting)
Charge Current 30A 20A 10A 5A
Terminate Current 1.5A/ 3A/ 6A 1.0A / 2A / 4A 0.5A/ 1A/ 2A 0.3A/ 0.5A/ 1A
Note: The return to charge voltage setting for Lithium Type battery is set to 13.3Vdc
