DC2DC Battery Charger Connections
SOLAR INPUT SOLAR INPUTBATTERY INPUT BATTERY INPUT BATTERY OUTPUT BATTERY OUTPUTIGNITION
Battery
Temperature
Sensor Port
Unit Ground
Remote Display
Port
(Remote Display
Sold Separately)
www.enerdrive.com.au
Page 15
Start Battery House BatterySolar Array
CH2 CH1CH3
