REPLACEMENT PARTS
To order replacement parts, specify serial number stamped onto nameplate, part description and number shown under
“Replacement Parts” in the next section. Replacement parts are available from any Energy Kinetics authorized Dealer.
Contact Energy Kinetics at 800-323-2066 or info@energykinetics.com for names of Dealers in your area.
AMULET REPLACEMENT
It is recommended that a new ceramic sleeve “amulet” be installed each time the air tube is removed from unit. See
instructions that come with each amulet. The Frontier amulet is larger than the standard amulet, so be sure to order the
proper part number shown in the Assembly Drawing. Using a standard amulet will allow excessive heat back to the front
jacket and may damage burner tube.
COMBUSTION CHAMBER REPLACEMENT
The combustion chamber is of high quality material and will normally not need to be replaced. A replacement chamber,
if required, is available from Energy Kinetics. The proper part number for the Frontier chamber must be specified when
ordering. For interim operation, the unit may be run without a combustion chamber if necessary. Ensure that the burner
head is protected by the amulet, wet pack or a similar material.
To install the replacement:
1. Open boiler by removing the nuts on the top center, middle left and right of the boiler. Note: Loosen, but do
not remove, the two 3/8” nuts on the bottom of the front jacket, the door is hinged upon these bolts. While
supporting the door, lower door slowly to the down position.
2. Spray chamber with a water mist to minimize disturbance and breakage of chamber material.
3. Remove the chamber support and remove chamber by tilting upward and rotating to loosen.
4. Locate and inspect the square dimple in the rear insulation board. The lower side of the chamber will insert into
this dimple.
5. Locate the 4”x2” support molded on the backside of the chamber and coat the 2” sides with refractory cement.
6. Insert chamber into the boiler with the exhaust opening in the 3 o’clock position. Chamber outlet must fit
behind or alongside the metal tab (supply nipple) in the top rear of the boiler.
7. With chamber fully inserted, slightly move the chamber until the chamber outlet is snug against the right side of
the boiler. The 4”x2” support on the back of the chamber should fit securely into the dimple on the rear
insulation board.
8. Re-insert chamber foot to support the front of the chamber.
9. Verify that the chamber is centered and ensure that the burner is centered with the chamber when closing the
front door. Secure and tighten the three nuts. Also check the two 3/8” nuts on the lower hinge bolts and
ensure that they are tight. Do not over tighten; tighten snugly enough to compress the door insulation.
10. Confirm proper setup and operation of burner (see "Gas Burner Operation").
WARNING: Ceramic fiber or fiberglass materials, may contain carcinogenic particles (cristobalite) after exposure to heat.
Airborne particles from fiberglass or ceramic fiber components have been listed as having potential health effects. Take the
following precautions when removing, replacing and handling these items.
Precautionary procedures:
Avoid breathing dust and avoid contact with skin or eyes. Wear long-sleeved, loose-fitting clothing, gloves and eye
protection. Use a properly fitted NIOSH certified respirator for dusty activities and where exposure levels are
unknown.
Use hand tools whenever possible if cutting or trimming is required. Power tools generate significantly more
airborne dust.
Use vacuums with HEPA-filters for clean up. If HEPA-filter vacuum are not feasible, lightly spray fiber materials
and work area with a water mist before sweeping or bagging of debris.
Wash exposed skin with soap and water after handling.
Do not use compressed air to clean work clothes or work area.
Wash work clothes separately from other clothing. Rinse washer thoroughly afterwards.
Avoid smoking, eating or drinking while dust is present in the work area.
