5.3 5.3 Initial OperationInitial Operation
Once all breakers are installed and power is present on
the inputs, remove the breaker compartment door and
slide the power switch to the on position� The power
switch is located on the front right side of the SmartSwitch�
The display will turn on and display the Alpha
®
logo
followed by the rmware version.
5.3.1 5.3.1 Breaker Inventory ProcessBreaker Inventory Process
Before the monitoring features of the Matrix panel can be
used, a breaker inventory must be taken�
Step 1. Upon rst power up, the system will prompt “TURN
ON THE BKRS HOLD 3S�”
Step 2. Turn on all breakers to be inventoried� Press and
hold the SmartSwitch as prompted�
Step 3. The SmartSwitch will now display the number of
breakers installed in the panel� If the number of
breakers displayed is incorrect, ensure that all
installed breakers are fully seated, in the correct
orientation, and turned on�
Step 4. If the number of breakers is correct, press and hold
the SmartSwitch for 3 seconds to continue�
Step 5. The SmartSwitch will now display “STORED
PRESS TO CONT�” Tap the SmartSwitch to
continue and set the breaker ampacity�
5.3.2 5.3.2 Setting Breaker AmpacitySetting Breaker Ampacity
The SmartSwitch will now display “SETUP BKR AMPS
HOLD 3S�”
Step 1. Hold the SmartSwitch for 3 seconds to enter the
menu to set breaker ampacity�
Step 2. The rst breaker in inventory will be shown, along
with its currently set ampacity� If the ampacity is
incorrect, press and hold the SmartSwitch for 3
seconds to enter the menu�
Step 3. Tap the SmartSwitch until the correct ampacity is
displayed (the display will advance through
standard Slimline breaker ampacities: 1, 3, 5, 10,
15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 65, 70, 80, 90,
and 100), then press and hold for 3 seconds to
save the value�
Step 4. The next breaker in inventory will now be displayed�
Repeat Steps 1-3 for each breaker in inventory�
Step 5. Once all of the breaker ampacities are set correctly,
advance to the screen that says “EXIT HOLD 3 S”
and hold the SmartSwitch for 3 seconds to exit the
menu and save the values�
This completes the initial SmartSwitch setup�
SETUP
BKR INV
HOLD 3 S
TURN ON
THE BKRS
HOLD 3 S
STORED
PRESS TO
CONT.
SETup
BKR AMPS
HOLD 3 S
