EnerSys alpha Matrix C16 User Manual

6
C048-725-30 Rev. B (01/2020)
1.0 1.0 Purpose and Applicability Purpose and Applicability
The purpose of this document is to detail the installation and
operation instructions for the Matrix C16
™
breaker panel�
1.1 1.1 Product ModelProduct Model
This document applies to the following congurations of the
Matrix C16 breaker panel:
Table 1. Matrix C16 Model Congurations
PART NUMBER DESCRIPTION
C016-1621-10 Matrix C16; Single Input; SmartSwitch
C016-1622-10 Matrix C16; Dual Input; SmartSwitch
C016-1623-10 Matrix C16; Single Input; LED Display, w/o Ethernet
C016-1624-10 Matrix C16; Dual Input; LED Display; w/o Ethernet
2.0 2.0 Theory of OperationTheory of Operation
2.1 2.1 IntroductionIntroduction
The Matrix C16 1RU High Power Density DC Distribution Center
provides high reliability, high power, DC distribution in a compact
1RU space to maximize rack space for signal equipment�
2.2 2.2 FeaturesFeatures
y Compact 1RU form factor
y 400A total rating
y 8A and 8B output circuits (dual input), 16 output circuits
(single Input)
y Enclosed breaker compartment to prevent nuisance trips
y Remote monitoring via Form-C dry alarm contacts
y SmartSwitch with per circuit current monitoring
y Available embedded web server for real time network
monitoring
3.0 3.0 Unpacking and InspectionUnpacking and Inspection
The Matrix C16 was carefully packaged at the factory to
withstand the normal rigors of shipping� However, you should
carefully inspect the box and contents to conrm that no damage
has occurred in transit. Most shipping carriers require notication
of shipping damage within twenty-four hours of delivery, and
it is the responsibility of the recipient to inspect the shipment
immediately upon receipt�
3.1 3.1 Package ContentsPackage Contents
y Matrix C16 1RU High Power Density DC Distribution Center
y Installation kit
y Rear plastic safety shields
