7.9 XForce thruster cable, fuse and battery requirements
XForce
Thruster
Motor
V/kW
Thrust
(KG)
Maximum cable length
1)
Minimum cable dimension Required min.
battery capacity Rec.
fuse
amp.
Spare fuse
P/N
Length m/ft Dim.
2)
mm
2
-AWG Ah/V
CCA
(SAE)
XF20
12/1.1 20 1-5/1-16 50-1/0 50 Ah/12 V 550 200 12-00200
XF40
12/2 40 1-4/1-13
4-8/13-26
50-1/0
70-2/0
100 Ah/12 V 800 300 12-00300
XF60
12/4 60 1-10/1-33
10-20/33-67
95-3/0
120-4/0
100 Ah/12 V 800 350 12-00350
XF60
24/4 60 1-10/1-33
10-20/33-67
95-3/0
95-3/0
100 Ah/24 V 800 300 12-00300
XF75
12/4 75 1-10/1-33
10-20/33-67
95-3/0
120-4/0
100 Ah/12 V 800 400 12-00400
XF75
24/4 75 1-10/1-33
10-20/33-67
95-3/0
95-3/0
150 Ah/24 V 1050 350 12-00350
XF90
12/4 90 1-10/1-33
10-20/33-67
95-3/0
120-4/0
100 Ah/12 V 800 400 12-00400
XF90
24/4 90 1-10/1-33
10-20/33-67
95-3/0
95-3/0
150 Ah/24 V 1050 350 12-00350
XF130
24/7 130 1-10/1-33 120-4/0 175 Ah/24 V 1150 400 12-00400
1) The distance from the thruster unit to the battery, one way, each cable.
Use of even larger cable dimensions and battery capacity will give the thrusters better performance.
2) Wiring insulation rating is 105°C (221°F) minimum.
