5 Operation
5.1. Cabin module menu system
5.1.1. Identification
A: Part number
B: Serial number
A
B
C
C: Manufacturing date
5.1.2. Logging in to the menu
CM
3
2
1
(SELECT) EXIT
4
SW7
Position
Description
1
Depress and hold down button SW7on the left and right joysticks for 5 seconds.*
2
Thumb roller in right grip.
3
Thumb roller in left grip.
4
Optional switch connected to the system.
*Applies to the standard configuration
