5 Operation
REMARKS
For quick hitches other than Q-Safe, follow the manufacturer's
instructions for checking that tools are correctly connected.
In the case of ECPUP, closed position is achieved when the red hook is in the closed
position.
In the case of engcon's other quick hitches, the blue indicator rod will no longer protrude
from the hitch. Indicator rod location may vary depending on the tiltrotator model.
If you have a different quick hitch, check that the lock function has engaged as specified
for the quick hitch concerned.
5.2.2. Disconnecting the tool, hydraulic lock
5.2.2.1. Opening the tiltrotator quick hitch (QH)
REMARKS
Machine hydraulics must be activated in order for the QSC
opening and closing function to work.
?
1.
1.
2.
2.
3.
3.
