Engcon DC2 QSC - Glossary; 10.1. Term Designations; 10.2. Abbreviations List

10 Glossary
10. Glossary
10.1. Designations
Term
Designations
Base machine
The machine carrying the equipment concerned. Excavator or backhoe loader.
Decal
Sticker with a symbol or logo that informs or warns.
Double feeder or
double pressure
reducer
Valve providing a double-acting function and used e.g. to obtain a tilt function on a
tilt bucket on a single-acting extra outlet.
Grip
The grip gripped by the operator to execute excavator movements and control the
tiltrotator and other tools.
Quick hitch lock
Locks a tool in the tiltrotator.
Stick
The 'arm' at the very front of the excavator.
Control systems
That which controls the tiltrotator and its functions. In certain cases, the control
system also control certain excavator functions.
Tiltrotator
A type of rotating and tilting quick hitch for excavators.
10.2. Abbreviations
Term
Description
CM
Cabin module.
EC
Tiltrotator
TM
Tiltrotator module.
QSC
Quick Hitch Standard Control is engcon's standardised locking system. It is able to
control all types of quick hitches on the excavator and beneath the tiltrotator.
QCM
QSC Q-safe cabin module
QLM
Q-Safe electronics module
QPM
QSC control panel
QH
Machine quick hitch
PA
Pressure activation (PA)
PA. CV
Control valve for pressure activation
PA. CVP
Push-button for control valve for pressure activation
