9 Decals
9.4.1.1. How to activate double-acting function
841155-B
3 SEC
Box
Description
1
Disconnect the connector on the stick.
2
Buzzer sounds.
3
Hold down the button in the MIG2 grip for 3 seconds (until a constant tone switches to
short beeps).
4
Double-acting function activated.
9.4.1.2. How to activate tiltrotator control
2 SEC
Box
Description
1
Connect the connector on the stick.
2
A buzzer will sound after 2 seconds.
3
Tiltrotator control activated.
