Engcon DC2 QSC - Design and Function; 3.1. DC2 Control System; 3.2. System Control Symbols

3 Design and function
3. Design and function
3.1. DC2
DC2 is a proportional control system with remote support. DC2 meets the requirements
placed on all components such as hydraulics, electronics and software. Used together
with engcon tiltrotators and Q-Safe, DC2 creates a safer work environment and also
enables track control, wheel control and boom slew. The engcon DC2 smartphone app
allows remote support to supplement the PC and USB cable connection.
3.2. Symbols
Track control
Track control
Wheel control
Base machine
Drive forward/reverse
Rotation/slew right/left
Tool change in the tool
programme
Feeder Swap
Rotation
Tilt
Shift between rotation
and Extra 2
Shift between tilt and
Extra 2
Open grab
Close grab
Shift between rotation
and grab
Shift between tilt
function and grab
Shift between Extra
and grab
Joystick function
9
