Engcon S60 - Lifting Points; Changing Tools

5 Operation
5.2. Lifting points
Approved
Not approved
Check the maximum permitted load for the jacking point as stamped on the lifting hook /
lug and rating plate. Designed with safety factor 5:1.
Lifting hook
Lifting lug
Part number
Designation
Max load
1072513
S60-upgrade kit-Lifting hook bolted 5T
5000 kg
1074575
S60-upgrade kit-Lifting ear bolted 5T
5000 kg
WARNING
The base machine must be equipped with a load-
holding valve on the boom/stick and an overload
warning when using a jacking point on the tiltrotator.
Risk of injury and damage to property.
5.3. Changing tools
The following instructions concern general operation of engcon machine couplers.
21
