5 Operation
Raise the machine coupler minimally above the ground so
that the tool engages the machine coupler.
Activate the quick coupler lock function. The quick coupler
lock is not fully connected to the attachment point until the
hydraulic system is activated and the "open" indicator is
no longer visible.
IMPORTANT
Always pressurize the machine
coupler to activate the locking
cylinder after changing tools.
Activate the hydraulics to operate the locking bolts.
IMPORTANT
Always pressurize the machine
coupler to activate the locking
cylinder after changing tools.
