5 Operation
The locking cylinders are activated.
The open position is achieved when the orange indicator
rod is visible. Q-Safe: The sound and light signals are
activated.
CAUTION
Use hearing protection
when in close proximity
to or operating the Q-
Safe machine coupler
when connected. Risk of
hearing loss.
In this position the tool is free !
The locking bolts are now in the open position and the tool
is released. Carefully lift the machine coupler away from
the tool.
