17
• The navigation drop-down menu on left is divided into seven main sections:
1. System: This menu includes the Operation Mode, Status, DHCP, Schedule, Event Log, and Monitor.
2. Wireless: This menu includes Status, Basic, Advanced, Security, Filter, Client List, and VLAN.
3. Network: This menu includes Status, LAN, and Spanning Tree.
4. Management: This menu includes the Admin, SNMP, Firmware, Configure, and Reset.
5. Tools: This menu includes Time Zone, Diagnostics, and LED Control.
6. Logout: Used to logout of the EAP150 User Interface. To login, user must open a new browser window.
