32
IQ System Controller 3 INT Quick Install Guide
LINK LED INDICATES
Flashing slowly
(200 ms high/1,800 ms low)
Searching for available network
Flashing slowly
(1,800 ms high/200 ms low)
Idle
Flashing quickly
(125 ms high/125 ms low)
Data transfer in progress
ISSUE ACTION
No communication with Enphase App after connecting the Cellular modem
to the IQ Gateway.
1. Disconnect the USB cable.
2. Reboot the IQ Gateway using the Enphase App or the Enphase
Installer App
3. Wait until the IQ Gateway boots completely.
4. Reconnect the Cellular modem USB cable.
I want to disconnect the modem and reuse it at a dierent site.
Moving the modem to a dierent
IQ Gateway deactivates the modem. Contact Enphase Customer
Support if you need to reinstall the modem at a dierent site.
POWER LED INDICATES
O DC power via USB not present
On DC power via USB present
SIGNAL LEDs DESCRIPTION INDICATES
All OFF Very weak signal
Bar 1 ON Weak signal
Bar 1 and 2 ON Good signal
Bar 1, 2, and 3 ON Very good signal
Troubleshooting:
LED status:
Check connection status and cellular
signal strength
When the IQ System Controller establishes an internet connection,
the IQ Gateway Network Communications LED is solid green. You
can use the Enphase Installer App to check the modem status and
cellular signal strength. The IQ Gateway’s AP (Access Point) Wi-Fi
network allows you to connect your mobile device (smartphone or
tablet) to the
IQ Gateway.
1. On the IQ Gateway, the AP Mode LED is solid green when the
AP mode is active. If the AP Mode LED is not lit, press the AP
Mode button.
2. Launch Enphase Installer App and tap connect to IQ Gateway.
3. Tap Network.
4. Under Network Conguration, tap Cellular. The app displays
connection status and an indication of signal strength.
5. Check the connection status and verify that signal strength is
at least two bars for adequate data transmission.
