enphase IQ System Controller 3 INT User Manual

5
IQ System Controller 3 INT Quick Install Guide
Section A - Mounting an IQ System Controller 3 INT
• IQ System Controller 3 INT is IP55 rated and can be mounted both indoors and
outdoors. Install the unit where it is not exposed to direct rainfall.
• Install this product where cables from PV, incoming mains, and batteries are
easily accesible and can be terminated at the IQ System Controller 3 INT.
• This product is designed to be installed on the wall only. Do not install this product
on the ground.
• The mounting surface must be able to support 15 kg.
• Follow all local standards and regulations while choosing a location for IQ System
Controller 3 INT.
• Do not install the product on the ceiling. The unit must be accessible.
• Do not install the product on a wall with a slope of more than 10 degrees.
• Product should be installed upright. Do not install the product tilting forward.
• The product operates within an ambient temperature range from -40°C to 50°C.
• Do not install this product in a place where it is directly exposed to sunlight.
• Do not install the product in a very dusty environment.
• This product must not be installed at altitudes above 2,000 m.
• In ood prone areas, ensure that the clearance from the ground is sucient to
avoid water ingress.
10°
-40°C
+50°C
2,000 m
Step 1:
Plan a location for mounting
the unit
