IQ7/IQ7+/IQ7X/IQ7A Microinverters Installation and Operation Manual
15 © 2023 Enphase Energy Inc. All rights reserved. September 2023
IOM-00028-1.0
3 Enphase microinverter Installation
Installing the Enphase IQ Series Microinverters involves several key steps. Each step listed here is
detailed in the following pages.
Step 1: Position the IQ Cable
Step 2: Position the Enphase IQ Aggregator
Step 3: Mount the microinverters
Step 4: Create an installation map
Step 5: Manage the cabling
Step 6: Connect the microinverters
Step 7: Terminate the unused end of the cable
Step 8: Complete the installation of the junction box
Step 9: Connect the PV modules
Step 10: Energize the system
Horizontal mount
Tie wraps or
cable clips
AC junction box
or isolator
