IQ7/IQ7+/IQ7X/IQ7A Microinverters Installation and Operation Manual
30 © 2023 Enphase Energy Inc. All rights reserved. September 2023
IOM-00028-1.0
4.8 Cabling options
Ordering options include:
Cable model
Connector
spacing
PV module
orientation
Connector count per
box
Q-12-10-240 1.3 m (50”) Portrait 240
Q-12-17-240 2.0 m (78”) Landscape (60-cell) 240
Q-12-20-200 2.3 m (90”) Landscape (72-cell) 200
The cabling system is flexible enough to adapt to almost any solar design. To determine the cable type
you need, apply the following considerations:
When mixing PV modules in both portrait and landscape orientation, you may need to
transition between cable types. See the preceding table for available cable types.
To transition between cable types, install an IQ Field Wireable Connector pair.
In situations where portrait modules are widely spaced, you may need to use landscape
spaced cables for the portrait-oriented PV modules and create loops of excess cable, if
needed.
WARNING: Do not form loops smaller than 12 cm (4.75") in diameter.
4.9 IQ Cable accessories
The IQ Cable is available with several accessory options for ease of installation, including:
• IQ Field Wireable Connectors (male): (Q-CONN-10M) Make connections from any Field
Wireable female connector
• IQ Field Wireable Connectors (female): (Q-CONN-10F) Make connections from any IQ Cable
open connector or Field Wireable male connector
• IQ Aggregator: (Q-BA-3-1P-60) Aggregates up to three fully populated 20 A branch circuits
and supports solar arrays of up to 11.5 kWac with a single rooftop aggregator
• IQ Raw Cable: (Q-12-RAW-200) 300 meters of 12 AWG cable with no connectors
• Cable clips: (Q-CLIP-100) Used to fasten cabling to the racking or to secure looped cabling
• IQ Disconnect Tool: (Q-DISC-10) Disconnect tool for IQ Cable connectors, DC connectors,
and AC module mount
• IQ Sealing Caps (female): (Q-SEAL-10) One needed to cover each unused connector on the
cabling
• IQ Terminator: (Q-TERM-10) Terminator cap for cut cable ends
