IQ7+ and I Q7A Installation and Operation Manual - India
11 © 2023 Enphase Energy Inc. All rights reserved. August 2023
USM-00002-1.0
Compatibility
The Enphase IQ Series Microinverters are electrically compatible with PV modules, as listed in the following
table. For specifications, see the Technical specifications in this manual. You can refer to Enphase
compatibility calculator to verify PV module electrical compatibility. To ensure mechanical compatibility, be
sure to order the correct connector type for both the microinverter and PV module from your distributor.
WARNING: Risk of fire. The PV module DC conductors must be labelled "PV Wire" or "PV Cable” to
comply with the NEC for ungrounded PV power systems.
Microinverter model
Connector type PV module cell count
IQ7PLUS-72-2-IN T, I Q7A-72-2-INT MC-4 locking type
60 cell/120 half-cell
66-cell/132 half-cell
NOTE: IQ Series Microinverters will not begin exporting power until the IQ Gateway is installed and
has detected all the microinverters at the site. In addition, the grid profile may need to be
configured, and the IQ Gateway must have propagated these settings to the microinverters. For
instructions on this procedure, refer to the IQ Gateway Installation and Operation Manual at the
documentation centre.
Earthing considerations
The microinverter has a Class II double-insulated rating, which includes ground fault protection (GFP). Refer
to local electrical codes and standards for earthing requirements of PV array and racking.
Branch circuit capacity
Plan your AC branch circuits to meet the following limits* for the maximum number of microinverters per
branch when protected with a 20 A MCB/fuse over the current protection device. For most three-phase
installations, use a 4-pole 20 A MCB/fuse.
Maximum* IQ Microinverters per AC branch circuit
Microinverter model
IQ7PLUS
I Q7A
36 (12 per phase branch circuit)
30 (10 per phase branch circuit)
*Limits may vary. Refer to local requirements to define the number of microinverters per branch in your area.
