Connecting the PSM Cables and AC Power Cords
SecureStack C2 Installation Guide 2-7
5. Oncertainswitches,anLEDindicator willshowthataredundantpowersupplyis
nowinoperation.
.
Figure 2-3 C2RPS-PSM Cable
Figure 2-4 Power Connectors on C2RPS-PSM(rear view)
Note: No change in switch configuration is necessary for this installation.
1 Redundant Power Supply connector 2 AC power connector (rear of chassis)
AC LINE
100-240 VAC
50-60 Hz
2A MAX
Redundant Power Supply
À Á
