Enterasys WS-AP3710i User Manual

Enterasys Wireless AP3710/AP3725 Installation Guide A-1
A
Specifications
This appendix lists the specifications for the WS-AP3710 and WS-AP3725 access points and the
Enterasys 48V DC power supply.
Table A-1 Specifications for the WS-AP3710 and WS-AP3725
Item Specification
Enclosure material Metal base, plastic housing
Power source 802.3af compliant PoE PD,
48V DC input
Power consumption < 12.94W (Max.)
Outside dimensions (max) WS-AP3725 Length: 190.5mm (7.5")
Width: 145mm to 180.0mm (7.5" to 7.09")
Thickness (not including mounting bracket): 29mm (1.13") to
38mm (1.5").
Antenna (AP3710i only) 6x internal antennas, single band
Uplink Interface GbE Ethernet x1 with PoE
RoHS compliant Yes
Radio Configuration IEEE 802.11a/b/g/n,
2.4/5GHz single-band,
Dual-radio, 3x3:2 MIMO
Operating temperature 32
o
F to 122
o
F (0
o
C to +50
o
C)
DRAFT

Enterasys WS-AP3710i Specifications

General

Brand	Enterasys
Model	WS-AP3710i
Category	Wireless Access Point
Language	English
