Enthermics DC150 - Dimension Drawings

SPECIFICATIONS
Blanket Warmer ▪ Oper a tor’s Ma nu al ▪ M N- 46 4 2 7 ▪ Rev 1 ▪ 6/19
14
Dimension Drawings
DC150 shown with Standard Feet
DC-DIM-006935
9.2 " (235mm)
IEC Cord Inlet
18.0 " (456mm)
39.1 " (994mm)
18.5 " (470mm)
17.0 " (431mm)
16.2 " (412mm)
14.4 " (366mm)
INSERT
10.1 " (258mm)
CAVITY
9.6 " (245mm)
INSERT
14.5 " (368mm)
CAVITY
17.7 " (450mm)
18.8 " (477mm)
20" (508mm)
13.5
" (344mm)
IEC Cord Inlet
15.5 " (394mm)
CAVITY
36.0 " (914mm)
Cord length: 6  (1.83m) (est.)
22.7 " (577mm)
