Enthermics DC250 - Page 36

34
MN-37072 • Rev 2 • 05/16 • Designer Series Blanket Warmer
Service
3
4
1
2
3
4
1
2
Item Description Part Qty
1Side cover, 1.5
3
1011024 2
1a Side cover, stainless steel, 1.5
3
1014261 2
1b Side cover, 2.5
3
1011269 2
1c Side cover, stainless steel, 2.5
3
1014268 2
1d Side cover, 3.5
3
1011288 2
1e Side cover, stainless steel, 3.5
3
1014275 2
1f Side cover, 4.0
3
1011472 2
1g Side cover, stainless steel, 4.0
3
1014282 2
1h Side cover, 7.5
3
1011588 2
1i Side cover, stainless steel, 7.5
3
1014289 2
2 Top cover, 1.5
3
1011029 1
2a
3
Top cover, stainless steel, 1.5
3
1014264 1
2b Top cover, 2.5
3
/3.5
3
1011266 1
2c Top cover, stainless steel, 2.5
3
/3.5
3
1014271 1
2d Top cover, 4.0
3
/7.5
3
1011475 1
2e Top cover, stainless steel, 4.0
3
/7.5
3
1014285 1
3 Rear cover, 1.5
3
5013520 1
Item Description
3a Rear cover, stainless steel, 1.5
3
1014262 1
3b Rear cover, 2.53 5013521 1
3c Rear cover, stainless steel, 2.5
3
1014269 1
3d Rear cover, 3.5
3
5013522 1
3e Rear cover, stainless steel, 3.5
3
1014276 1
3f Rear cover, 4.0
3
5013643 1
3g Rear cover, stainless steel, 4.0
3
1014283 1
3h Rear cover, 7.5
3
5018517 1
3i Rear cover, stainless steel, 7.5
3
1014290 1
4 Bottom cover, 1.5
3
5013523 1
4a Bottom cover, stainless steel, 1.5
3
1014263 1
4b Bottom cover, 2.5
3
/3.5
3
5013524 1
4c Bottom cover, stainless steel, 2.5
3
/3.5
3
1014270 1
4d Bottom cover, 4.0
3
/7.5
3
5013644 1
4e Bottom cover, stainless steel, 4.0
3
/7.5
3
1014284 1
Part Qty
Full Assembly A
Part numbers and drawings are subject to change without notice.
Serial number is required for all inquiries.
Always include both model and serial number(s) in any
correspondence regarding the appliance.
Model: ______________________________________________
Serial Number: ______________________________________________
