39
MN-37072 • Rev 2 • 05/16 • Designer Series Blanket Warmer
Service
Part numbers and drawings are subject to change without notice.
Serial number is required for all inquiries.
Always include both model and serial number(s) in any
correspondence regarding the appliance.
Model: ______________________________________________
Serial Number: ______________________________________________
Purchased From: ______________________________________________
Date Installed: ____________________ Voltage: _____________
Control Interface
16
9
4
5
12
14
7
2
10
3
15
1311
6
1
8
16
9
4
5
12
14
7
2
10
3
15
1311
6
1
8
Item Description Part Qty
1 Panel, interface mount, 18.5", 1.5
3
/2.5
3
/3.5
3
1011336 1
1a Panel, interface mount, 24", 4.0
3
/7.5
3
1011482 1
2 Panel, front top trim, painted, 18.5", 1.5
3
/2.5
3
/3.5
3
1011032 1
2a Panel, front top trim, painted, 24", 4.0
3
/7.5
3
1011481 1
2b Panel, front top trim, stainless steel, 18.5", 1.5
3
/2.5
3
/3.5
3
1014265 1
2c Panel, front top trim, stainless steel, 24", 4.0
3
/7.5
3
1014286 1
3 Control, assembly service kit 5015524 1
4 Cover button, 18.5", 1.5
3
/2.5
3
/3.5
3
CV-29256 1
4a Cover button, 24", 4.0
3
/7.5
3
CV-29345 1
4b Cover button, with timer, 18.5", 1.5
3
/2.5
3
/3.5
3
CV-29434 1
4c Cover button, with timer, 24", 4.0
3
/7.5
3
CV-35433 1
5 Plate, button retainer 1011149 1
6 Control, service kit 5018020 1
Circuit board, display BA-34868 1
8 Cable, 3.5" display CB-35192 1
9 Latch, button LT-29176 1
10 Screw, pan head phillips, M3 x 8 SC-29332 4
11 Screw, pan head phillips, M4 x 12 SC-29333 15
12 Spring, compression SD-29371 1
13 Washer, flat WS-22323 1
14 Washer, flat WS-23991 1
15 Washer, flat WS-25056 1
16 Overlay, auto timer (optional) PE-34864 1
7
