Entrematic Ditec DAS200HD - PAS005 AP and PAS024 Sensor Connections

48
IP2266EN
EN
i
For more information on sensors, refer to the relevant installation manuals.
PAS024ADT (1)
White
Brown
Green
Red
Black
Grey/Pink
Red/Blue
17
15
15
Yellow
16
Pink
9
17
13
17
10
Blue 15
PAS024AMR (1)
Green
Brown
Yellow
Red
Blue
Yellow/Black
Red/Blue
17
15
10
White
16
Pink
9
17
13
Grey 15
PAS005AP (1)
Green
Brown
Yellow
White
Pink
Grey
Red
Blue
7
1
1
2
7
6
Green
Brown
Yellow
White
Pink
Grey
Red
Blue
PAS005AP
(2)
7
1
1
4
7
6
Set the selection DIP switches on sensor PAS024ADT as shown below:
INNER SENSOR
INNER SENSOR
14
ON
7 8
