2. Technical data
2.1 Operating instructions
Service class: 5 (minimum 5 years of working life with 600 cycles per day).
Applications: HEAVY DUTY (for entrances with very intense pedestrian use).
• The performance characteristics refer to the recommended weight (approx. 2/3 of the ma-
ximum weight allowed). When used with the maximum permissible weight a reduction in
the above mentioned performance can be expected.
• The service class and number of consecutive cycles should be taken merely as a rough
indication. having been statistically determined under average operating conditions, and
are therefore not necessarily applicable to specific conditions of use.
• Each automatic entrance has variable elements such as: friction, balancing and envi-
ronmental factors, all of which may substantially alter the performance characteristics of
the automatic entrance or curtail its working life or parts thereof (including the automatic
devices themselves). The installer should adopt suitable safety conditions for each parti-
cular installation.
Ditec DAS200
Ditec DAS200HD
Ditec DAS200RF
Ditec DAS200RG
Power supply
110V~ / 240V~
50/60Hz
110V~ / 240V~
50/60Hz
110V~ / 240V~
50/60Hz
Power supply rated
power (PS)
75W 150W 150W
Max Opening speed
(2 door wings)
1,3m/s 1,4m/s 1,4m/s
Maximum load
120kg (1 wing)
200kg (2 wings)
150kg (1 wing)
DAS200HD 280kg (2 wings)
DAS200RF 240kg (1 wing)
150kg (1 wing)
280kg (2 wings)
Service class
5
(HEAVY DUTY)
5
(HEAVY DUTY)
5
(HEAVY DUTY)
Intermittence S3=100% S3=100% S3=100%
Temperature
-20°C +50°C
-20°C +50°C
-20°C +50°C
Degree of protection
IP20
(FOR INTERNAL USE ONLY)
IP20
(FOR INTERNAL USE ONLY)
IP20
(FOR INTERNAL USE ONLY)
Control panel
(MCU/MCU-ER)
1DAS20QE 1DAS20HDQE 1DAS20RGQE
Accessories power
supply
24V
0,64A 24V 1A 24V 1A
Durability test 1.000.000 cycles 1.000.000 cycles 1.000.000 cycles
