P a g e | 128
7 The Envision® Gas Analyzer Configuration Editor Software
The handheld computer software can utilize an ID set created by the user on a Windows based desktop
or laptop computer. This configuration editor software is provided by Elkins Earthworks® and is
included on the flash drive with your original purchase. This software allows the user to create, modify
and merge data sets.
The instructions below describe the process of generating a new ID set to import into the handheld
computer.
It is important to use the proper configure configuration editor that corresponds to the models of
Envision and handheld computer that you are using. These are shown below.
Name of Configuration Editor (shows in title bar)
ENV100 & ENV200 – Handheld PC
Elkins Gas Analyzer Configuration Editor
ENV100 & ENV200 – Tablet PC
Elkins Gas Analyzer Configuration Editor Tablet
Elkins Gas Analyzer Configuration Editor BH (BH =
borehole)
Most of the screen shots below will show the ENV100/200 handheld PC version of the configuration
editor.
7.1 Loading the application
The flash drive delivered with the Envision® gas analyzer contains a file named “Configuration Editor”.
Insert the flash drive into an unused USB port on the user’s computer.
7.2 Opening the Gas Analyzer Configuration Editor for the first time
When the Gas Analyzer Configuration Editor is selected for the first time it will indicate “No
Configuration File found”. The software will create sample data when the user presses the “OK” button.
Newer versions of the ENV100/200 software will not automatically create a sample data file. They allow
the user to create a new ID set using the “File -> New” menu. The user will then be asked whether the
ID set should contain metric or English units. The sample file will then be created with the units
specified.
