5.3 Lowering speed, laden/
unladen
fpm m/ s 0.05 / 0.026 0.05/0.026
5.8 Max. gradeability, laden/
unladen
% 5 / 16 8\16
5.10 Service brake type Electrom
agnetic
Electrom
agnetic
Electric-engine
6.1 Drive motor rating S2 60 min hp kW 0.9 0.9
6.2 Lift motor rating at S3 15% hp kW 0.84 0.84
6.4 Battery voltage/nominal
capacity K5
V/ Ah 12*4/30Ah 48/20Ah
6.5 Battery weight lb. kg 9.5*4 12
Addition data
8.1 Type of drive control DC DC
10.5 Steering type mechanical mechanical
10.7 Sound pressure level at the
driver’s ear
dB (A) <74 74
a=200mm
3.2 Tyre size, driving
wheels(diameter×width)
mm Ф210x70 Ф210x70
3.3 Tyre size, loading
wheels(diameter×width)
mm 2×Ф80x61 2x Ф80x61(
Ф74x88)
3.4 Tyre size, caster
wheels(diameter×width)
mm Ф74x30 Ф74x30
3.5 Wheels, number driving, caster/
loading (x=drive wheels)
mm 1×,2/4 1x 2/4
3.6.1 Track width, front,driving side b10 mm 450 438
3.7.1 Track width,rear,loading side b11 mm 410(535) 410(535)
Dimensions
4.4 Lift height h3 mm 115 115
4.9 Height drawbar in driving position
min./max.
h14 mm 750 / 1170 750/1170
4.15 Lowered height h13 mm 80 80
4.19 Overall length l1 mm 1626 1626
4.20 Length to face of forks l2 mm 476 476
4.21 Overall width b1/ b2 mm 680 680
4.22 Fork dimensions s/ e/ l mm 50×150×1150 50/150/1150
4.25 Distance between fork-arms b5 mm 560(685) 560(685)
4.32 Ground clearance, center of
wheelbase
m2 mm 30 30
4.34.1 Aisle width for pallets 1000 × 1200
crossways
Ast mm 2217 2217
4.34.2 Aisle width for pallets 800 × 1200
lengthways
Ast mm 2279 2279
4.35 Turning radius Wa mm 1460 1460
Performance data
5.1 Travel speed, laden/ unladen km/ h km/h 5 / 5.5 5 / 5.5
5.2 Lifting speed, laden/ unladen m/ s 0.017/0.021 0.017/0.021
