Intended use
The lift truck is designed for transporting and stacking the loads stated in the
nameplate.
In particular we refer to:
• the safety rules of your trade association.
• In accordance with the special provisions for driving on public roads specied by national
specications.
• Other local regulations.
The rules for the intended and approved use of industrial trucks must be followed under all
circumstances by the responsible persons, especially by the operator and service personnel.
The user, and not manufacturer, is responsible for any danger arising from applications not
authorised by the manufacturer.
If you want to use the truck for applications not mentioned in this manual, please rst contact your
authorised dealer.
No changes, particularly no modications and additions, may be made to the truck without the
approval of the manufacturer.
Technical description
• These trucks consists of robust steel chassis and is driving on a traction wheel and 2 load wheels.
Caster wheels provide for good stability even with high loads.
• The truck will be stopped by a regenerative service brake and hold by an automatic
electromagnetic parking brake in it’s parking position.
• The load is lifted by a hydraulic cylinder that activates a lifting shaft that transmits the lifting
movement by a push-rod to the load wheels.
• The control handle is used for smooth steering and control of drive speed, lifting and lowering,
braking and the horn without changing the position of the hand. The long tiller shaft allows
e󰀨ortless steering and a safe distance to the truck. A gas spring returns the control handle always
into a vertical position that activates the brake automatically.
• An emergency reverse switch on the control head protects the operator from being squeezed by
the truck in conned spaces.
• An electronic controller operates all electric functions and guaranties safety.
• A key switch secures the truck from unauthorized use.
• The ergonomic design of the truck guaranties safe and easy operation.
In the manual, “equipment user” refers to any natural person or legal person directly using or
appointing or authorizing others to use the carrier. In such special situations as renting or sales,
the “equipment user” represents the interested parties supposed to bear operation obligations
as specied by the contractual terms concluded between equipment owner and corresponding
users. Equipment users must ensure the use of the carrier only for purposes specied and timely
eliminate all the dangers that may threaten the life and health of the users themselves or any other
third party, in addition to which they must also strictly abide by accident prevention provisions,
other safety technology provisions and equipment operation, maintenance and repair guidelines,
and ensure that all the operators seriously read and completely understand the contents of the
operation instruction.
Should any violation of the operation instruction occur, the quality guarantee of our company will be
invalid automatically, and our company will assume none of the responsibilities for losses resulting
from any nonstandard operation of the equipment implemented by any client, equipment user or
any third party without the authorization of the client service department of our company.
Obligations and responsibilities of equipment user
Modication
Unauthorized modication to the truck can result in injury or death.
Can not remove, disable or modify any safeguards or other safety devices.
Exception:Only in the event that the truck manufacturer is no longer in business and there is no
successor in the interest to the business, may the user arrange for a modication or alteration to a
powered industrial truck, provided, however, that the user
a) arranges for the modication or alteration to be designed, tested and
implemented by an engineer(s) expert in industrial trucks and their safety.
b)maintains a permanent record of the design, test(s) and implementation of the modication or
alteration.
c) approves and makes appropriate changes to the capacity plate(s), decals, tags and operation
manual.
d) a󰀩xes a permanent and readily visible label to the truck stating the manner in which the truck
has been modied or altered, together with the date of the modication or alteration and the name
and address of the organization that accomplished those tasks.
Wind forces can a󰀨ect the stability of a truck when lfting, lowering and transporting loads with large
surface areas .
Light loads must be especially secured when they are subjected to wind forces. This will prevent
the load from sliding or falling.
Stop the truck in both cases.
Wind loads
This manual is used for operation and maintenance, the detail parameters, size and specication
s in context is only for reference , the real parameters will depend on sale les.
Manual pictures for reference only, the real car shall prevail, and shall not a󰀨ect the manual use.
Manual pictures only sign for one of the models in this series models.
Schematic views
