20
BATT1 battery capacity
①
13%~35%
BATT2 battery capacity
①
13%~35%
BATT1 battery capacity
①
36%~61%
BATT2 battery capacity
①
36%~61%
BATT1 battery capacity
①
62%~86%
BATT2 battery capacity
①
62%~86%
BATT1 battery capacity
①
87%~100%
BATT2 battery capacity
①
87%~100%
Day
PV array
Night
BATT1 charging icon
Display the parameters of
PV
BATT2 charging icon
Display the parameters of
BATT1
BATT1 temperature
parameters
Display the parameters of
BATT2
AES signal icon
Setting icon
Battery type icon
Auto global browsing icon
Minimum voltage icon
Fault Icon
Maximum voltage icon
① The linear relationship between the LVD voltage and float charging voltage
calculates the battery capacity.
 Fault indication
Fault
Fault
indicator
Charge
indicator
LCD
Instruction
BATT1
overvoltage
Red
Fast
flashing
——
Battery capacity
shows full, battery
frame blink, fault icon
