Epever DR3210N-DDS - Battery Voltage Parameters; Lead-acid Battery Voltage Settings

24
APP under the "User" battery type.
1) Lead-acid Battery Voltage Parameters
The parameters are in the 12V system at 25 ºC; please double the values in the
24V system.
Battery type
Voltage parameter
Sealed
Gel
Flooded
User
Over Voltage Disconnect Voltage
16.0V
16.0V
16.0V
9~17V
①
Charging Limit Voltage
15.0V
15.0V
15.0V
Over Voltage Reconnect Voltage
15.0V
15.0V
15.0V
Equalize Charging Voltage
14.6V
——
14.8V
Boost Charging Voltage
14.4V
14.2V
14.6V
Float Charging Voltage
13.8V
13.8V
13.8V
Boost Reconnect Charging Voltage
13.2V
13.2V
13.2V
Low Voltage Reconnect Voltage
12.6V
12.6V
12.6V
Under Voltage Warning Reconnect
Voltage
12.2V
12.2V
12.2V
Under Volt. Warning Volt.
12.0V
12.0V
12.0V
Low Volt. Disconnect Volt.
11.1V
11.1V
11.1V
Discharging Limit Voltage
10.6V
10.6V
10.6V
Equalize Duration (min.)
120
——
120
0~180
Boost Duration (min.)
120
120
120
10~180
① The DR1106/2106/3106N-DDB/DDS voltage is 9-16V.
The following rules must be observed when modifying the parameter's value in
user battery type (factory default value is the same as sealed type):
A. Over Voltage Disconnect Voltage > Charging Limit Voltage ≥ Equalize Charging
Voltage ≥ Boost Charging Voltage ≥ Float Charging Voltage > Boost Reconnect
Charging Voltage.
B. Over Voltage Disconnect Voltage > Over Voltage Reconnect Voltage
C. Low Voltage Reconnect Voltage > Low Voltage Disconnect Voltage ≥ Discharging
Limit Voltage.
D. Under Voltage Warning Reconnect Voltage > Under Voltage Warning Voltage ≥
Discharging Limit Voltage.
E. Boost Reconnect Charging voltage > Low Voltage Reconnect Voltage.
