SB[,{S|R|1|0}] - Standby
This command enables/disables the output. Entering the command without parameters displays the present standby
status. The commands
SB,S
and
SB,1
switch the unit to standby mode, the output is disabled. The commands
SB,R
and
SB,0
disable the standby mode, the output is enabled.
Example:
GTR Remote operation mode
OVP,200 Over voltage protection 200 V
UA,100 Output voltage 100 V
IA,10 Output current 10 A
SB,R Output is active
SB Retrieve standby status
SB,R Unit answers: output is active
SCR[,<CMD>[,<value>]] - Load Script
With this command the script memory can be programmed. The command
SCR
without parameters initializes the
programming procedure. The command
SCR
with parameters writes the commands into the script memory. The
order of the commands corresponds to the order of commands of the script. Script commands and their parameters
are described in the chapter Script Control.
Example:
GTR Remote operation mode
OVP,200 Over voltage protection 200 V
SCR Initialisation of script programming
SCR,U,12 1. script command: U = 12 V
SCR,I,15 2. script command: I = 15 A
SCR,UI 3. script command: mode UI
SCR,RUN 4. script command: activate output
SCR,LOOPCNT,10 5. start address loop
SCR,U,12 6. script command: U = 12 V
SCR,DELAY,8 7. script command: wait 8 ms
SCR,U,1 8. script command: U = 1 V
SCR,DELAY,1000 9. script command: wait 1 s
MODE,SKRIPT Activate script mode
SB,R Start script
SS or *PDU - Save Setup
Saves present unit parameters (interface parameter and controller parameter). No return value.
STATUS - Status
Query of device status. Return value in binary units. Function of the bits within the status byte:
Bit Function
D15
Number of units in M/S mode. If no other device is
connected, 1 is displayed, if two devices are connected to
the bus, 2 is displayed etc. If M/S mode was disabled via
configuration menu, 0 is displayed.
D14
D13
D12
D11
-
reserved
-
D10
-
reserved
-
D9
-
reserved
-
D8
Limit mode, unit in power limitation mode
D7
Limit mode, unit in current limitation mode
D6
Local lockout (1 = LLO active, 0 = LLO not active)
D5
Local (1 = front panel
operation)
D4
Remote (1 = digital interface operation)
D3
-
reserved
-
D2
-
reserved
-
D1
Standby (1 = unit in standby mode)
D0
OVP (1 = shut down by over voltage protection)
