EPS RS 232 - External Control - AI Interface; AI Interface Overview

Ext. Control: AI Interface (Option)
0
1
0
Command
0
1
1
Range
1
0
0
Unit
1
0
1
Hardware
1
1
0
Read
Interface parameters are configured via software using the command <PCx> . The settings can be saved with the
command <SS> .
Interface Reconfiguration
In case, the user has forgotten the active setup, there are two ways of reconfiguring the interface:
• sending the command <PCx> from one of the other interfaces
• using the display to configure the interface  Interface Parameters
EXT. CONTROL: AI INTERFACE (OPTION)
The device can be controlled via control signals and by using the analog/digital In/Out.
