EPS RS 232 - Response String

Universal interface (Option)
24
WAVERESET,<U
max
><I
max
> - Start Userwave Data
Starts the transfer of a user defined output characteristic. The parameters U
max
and I
max
define the maximum voltage
of the output characteristic. Afterwards, the fulcrums of the UI characteristic can be entered using the command
DAT . The characteristic ends with the commands WAVE or WAVELIN .
Example:
GTR Remote operation mode
OVP,200 Over voltage protection 200 V
WAVERESET,100,10 Output characteristic with a maximum of 100 V and 10 A
DAT,90,1 Fulcrum 90 V, 1 A
DAT,50,5 Fulcrum 50 V, 5 A
DAT,10,9 Fulcrum 10 V, 9 A
WAVELIN End of characteristic, linear interpolation
MODE,USER Activates the created UI characteristic
SB,R Output active
For more information and examples of user defined characteristics see  Wave, Wavelin and Programming of
characteristics (Script Operation).
Response String
The response string has the following format:
command comma value unit <CR> <LF>
The value is a floating point string with a ‘.‘ as delimiter.
Command Response Command Response
IA
IA,12.34A
MU
MU,10.0V
LIMU
LIMU,500.0V
PA
PA,12W
LIMI
LIMI,30.00A
RA
RA,0.015R
LIMP
LIMP,15000W
UA
UA,100.0V
LIMRMIN
LIMRMIN,0.015R
UMPP
UMPP,90.2V
LIMRMAX
LIMRMAX,0.110R
IMPP
IMPP,10.01A
LIMR
LIMR,0.015R,0.110R
OVP
OVP,600.0V
Example: Command as ASCII and HEX protocol
L I M U , 5 0 0 . 0 V
4C 49 4D 55 2C 35 30 30 2E 30 56 0D 0A
The digits after the decimal point correspond to the resolution of the unit.
Example
UA at a 600 V unit UA,123.4V
UA at a 50 V unit UA,23.44V
The digits before the decimal point depend on the present measurement value.
Example: 600 V unit
UA,10.4V
UA,220.3V
UA,1.1V
Example: 50 V unit
UA,1.23V
UA,10.47V
UA,0.01V
