Technical Specifications
4
TECHNICAL SPECIFICATIONS
A MBIENT C ONDITIONS
Cooling
Fan
Operating temperature
0 - 50 °C
Storage temperature
-20 - 70 °C
Humidity
< 80 %
Operating altitude
< 2000 m
Vibration
10 - 55 Hz/1 min/2G XYZ
Shock
< 20 G
Weight
5 kW 19 kg, 10 kW 26 kg, 15 kW 33 kg
I NPUT S PECIFICATIONS
EPS/MP models
(by max output power)
1.2 kW 2.4 kW
Connection
3 wire (1P+N+E)
AC socket on rear panel
IEC-C14 IEC-C20
Input voltage
230 V
ac
, 50/60 Hz (207-253 V
ac
47-63 Hz)
Input current
1
,
2
≈ 6.5 A
≈ 13 A
Inrush transient current
2
≈ 25 A
≈ 25 A
Main input fuse rating
10 A
16 A
Main input fuse type and location
built-in fast acting PCB mounted cartridge fuse
Recommended supply breaker value
& curve
16 A type D 16 A type D
Leakage current
≈ 1.5 mA
≈ 1.5 mA
THD input current
≈ 3.75 %
≈ 10.75 %
THD input voltage
≈ 1.87 %
≈ 2.55 %
Power factor
≈ 0.99
≈ 0.99
Efficiency type
1
≈ 88 % (with PFC)
≈ 89 % (with PFC)
Dissipated power
1
≈ 165 W
≈ 350 W
O UTPUT S PECIFICATIONS
Static voltage regulation
± 0.05 % + 2 mV
Static current regulation
± 0.1 % + 2 mA
Dynamic regulation
< 1-3 ms (typ.)
Ripple
< 0.2 % RMS (typ.)
Stability
± 0.05 %
Programming accuracy (V
out
)
± 0.05 % +2 mV
Programming accuracy (I
out
)
± 0.05 % +2 mA
Display accuracy (V
out
)
< ± 0.5%
Display accuracy (I
out
)
< ± 0.5%
Isolation
3,000 V
Over voltage protection
0 - 120 % V
max
Circuit protection
OC/OV/OT/OP
Line regulation
< ± 0.1 % + 2 mV
1
for nominal output voltage and nominal output current
2
for nominal input voltage
