Epson Aculaser C1700 Series - Chapter 2 Basic Operation; Main Components; Front View

Chapter 2
Basic Operation
Main Components
This section provides an overview of your Epson AcuLaser C1700 series.
Front View
12 3 4
12 11 10 9 8 7 6 5
1 Operator Panel 2 Center Output Tray
3 Output Tray Extension 4 Print Head Cleaning Rod
5 Toner Access Cover 6 Power Switch
7 Paper Width Guides 8 Multipurpose feeder (MPF)
9Front Cover 10Slide Bar
11 Length Guide 12 Paper Cover
