Epson BrightLink 455Wi Installation Guide

2
Safety Instructions
For your safety, read all the instructions in this guide before using the setting plate. Incorrect handling that
ignores instructions in this guide could damage the setting plate or could result in personal injury or property
damage. Keep this installation guide at hand for future reference.
Read the safety instructions in the User's Guide for your projector and follow the instructions in this
document.
Explanation of Symbols
The warning marks shown below are used throughout this installation guide to prevent personal injury or
property damage. Make sure you understand these warnings when reading this installation guide.
Safety Precautions for Installation
This symbol indicates information that, if ignored, could possibly result in personal injury or even death
due to incorrect handling.
This symbol indicates information that, if ignored, could possibly result in personal injury or physical
damage due to incorrect handling.
Symbol indicating an action that must not be done
Symbol indicating an action that should be done
The setting plate is designed specifically for mounting a projector to a wall. If anything other than a
projector is mounted, the weight may result in damage.
If the setting plate falls, it could cause personal injury or property damage.
The installation work (wall mounting) should be performed by specialists who have technical knowledge
and ability. Incomplete or incorrect installation could cause the setting plate to fall and cause personal
injury or property damage. Contact the customer support office listed in “Where to Get Help” in the User's
Guide for your projector when installing the setting plate.
Follow the instructions in this guide when installing the setting plate.
If the instructions are not followed, the setting plate may fall, resulting in personal injury or property damage.
Handle the power cable carefully.
Incorrect handling may cause fire or electric shock. Observe the following precautions when handling:
• Do not handle the power plug with wet hands.
• Do not use a power cable that is damaged or modified.
• Do not pull the power cable with too much force when routing the cable through the setting plate.
When you mount the projector on the wall with the setting plate, the wall requires enough strength to hold
the projector and the setting plate. Confirm the weight of the projector and the setting plate before
installation, and maintain the strength of the wall. If the wall is not strong enough, reinforce the wall
before installation.
Do not install the setting plate in a place where it might be subjected to vibration or shock.
Vibration or shock could cause damage to the projector or mounting surface. It could also cause the setting plate or
projector to fall and cause personal injury or property damage.
Install the setting plate so that it can sufficiently support the weight of the projector and setting plate, and
resist any horizontal vibration. Use M8 nuts and bolts.
Nuts and bolts smaller than M8 could cause the setting plate to fall. Epson takes no responsibility for any damage or
injury caused by incorrect installation.
Warning
Caution
Warning

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
