Epson BrightLink 455Wi Installation Guide

7
English
2. Specifications
Wall plate
Setting plate adjustment range
Item Specification Remark Reference Page
Setting plate weight Approx. 13.89 lb
(6.3 kg)
Wall plate 4.85 lb (2.2 kg)
Covers and cap 1.04 lb (0.47 kg)
Forward/backward slide
adjustment range
0 to 11.81 in.
(300 mm)
Refer to the figure
below
Vertical slide adjustment range 4 ° Minimum: 1.10 in. (28 mm)
Maximum: 1.67 in. (42.5 mm)
s 25
Vertical tilt adjustment range ± 5 ° Fine adjustments possible with adjustment dial
s 24
Horizontal rotation adjustment
range
± 5 ° Fine adjustments possible with adjustment dial
s 24
Horizontal roll adjustment range ± 3 ° Fine adjustments possible with adjustment dial
s 23
Horizontal slide adjustment range ± 1.77 in.
(45 mm)
Refer to the figure
below
[Unit: in. (mm)]
9.87 (250)
17.97 (456)
9.05 (230)
8.74 (222)
6.3 (160)
9.71 (247)
0.59 (15)
4.4 (112)
8 (203.2)
3.0
(76)
1.8 (46)
4.75
(121)
1.81 (46)
Forward/backward slide adjustment range:
0 to 11.81 in. (300 mm)
Horizontal slide adjustment range:
± 1.77 in. (45 mm)

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
