Epson BrightLink 455Wi Installation Guide

4
1 Package Contents
s Page 5
2 Specifications
s Page 7
3 Connecting Devices
s Page 8
4 Positioning the Projector
s Page 9
(1) Installation worksheet for projecting on a pre-installed wall-
mounted board
(2) Installation worksheet for projecting on a plain wall
(3) Installation measurements in inches
(4) Installation measurements in millimeters
5 Installing the Projector
s Page 17
(1) Install the wall plate on the wall
(2) Determine the projection distance and pull out the slider
(3) Attach the setting plate to the wall plate
(4) Secure the projector to the setting plate
(5) Connect the power cable and other cables to the projector
6 Adjusting the Image
s Page 21
(1) Turn on the projector
(2) Display the test pattern
(3) Change the aspect ratio if necessary
(4) Adjust the focus
(5) Use the left adjustment dial to adjust the horizontal roll
(6) Use the right adjustment dial to adjust the horizontal rotation
(7) Use the top adjustment dial to adjust the vertical tilt
(8) Adjust the vertical position
(9) Adjust the forward/backward slide
(10) Turn off the display of the test pattern or computer image
7 Attaching the Covers
s Page 26
(1) Attach the wall plate cover and end cap
(2) Attach the cable cover to the projector

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
