Epson DFX-9000 User Manual

Installing the Ribbon Cartridge 5
English
5. Lift up the black plastic ribbon guide and slide it down behind the print
head until it clicks into place. Do not twist or crease the ribbon.
6. Slide the print head back and forth to make sure it moves freely. If not, lift
up the ribbon guide and try again.
7. Turn the ribbon-tightening knob to remove any slack.
8. Close the top cover.
Note:
For safety reasons, the printer will not work if the top cover is not closed completely.
ribbon tightening knob
http://www.ochimp.com
http://www.ochimp.com
For More Info
Click Here ===>

Epson DFX-9000 Specifications

General

Color	No
Built-in barcodes	Code 39, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Maximum print size	A4 (210 x 297 mm)
Standard interfaces	Serial
Dimensions (WxDxH)	700 x 378 x 363 mm
Power requirements	100-240V, 50-60Hz
Connectivity technology	Wired
Compatible operating systems	Microsoft Windows 95 / 98 / 2000 / Me / XP/ Windows NT 4.0
Sound pressure level (printing)	58 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Power consumption (standby)	1.85 W
Power consumption (typical)	7.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
