Epson DFX-9000 User Manual

8 Installing and Using the Remote Configuration Manager
Installing and Using the Remote Configuration
Manager
The Epson Remote Configuration Manager provides an easy way to change your
printer’s default settings in Windows. Follow these steps to install it:
1. Select
Install EPSON Remote Configuration Manager on the Installation
screen and click .
2. When you see the InstallShield window, click
Yes. You see this screen:
3. Click
Next and follow the on-screen instructions.
4. When the installation is complete, click
Finish. (You may need to close a
window on your screen to see the final installation screen.)
To start the program, select
Programs (or All Programs) > Epson Remote
Configuration Mgr > Epson Remote Configuration Manager
.
To open the program’s on-screen User’s Guide , select Programs (or All
Programs
) > Epson Remote Configuration Mgr > Epson Remote Configuration
Manager User’s Guide
.
Note:
If you are using the serial port, you need to switch the printer driver to COM2 before
you run the Remote Configuration Manager. Switch it back to COM1 when you’re
done.
http://www.ochimp.com
http://www.ochimp.com
For More Info
Click Here ===>

Epson DFX-9000 Specifications

General

Color	No
Built-in barcodes	Code 39, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Maximum print size	A4 (210 x 297 mm)
Standard interfaces	Serial
Dimensions (WxDxH)	700 x 378 x 363 mm
Power requirements	100-240V, 50-60Hz
Connectivity technology	Wired
Compatible operating systems	Microsoft Windows 95 / 98 / 2000 / Me / XP/ Windows NT 4.0
Sound pressure level (printing)	58 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Power consumption (standby)	1.85 W
Power consumption (typical)	7.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
