26
Power Supply Unit (PS-180)
Material
The product is free of brominated materials, such as PBBE and PBB.
Suitable AC cables
Use an AC cable meeting the following requirements.
• Product compliant with safety standards
• Product whose plug is equipped with P and E terminals
Grounding
Connect the ground cable for safety.
Specification overview
Electrical
characteris-
tics
Input conditions Input voltage (rated): AC 90 to 264 V (AC 100 V -10% to AC 230 V + 15%)
Frequency (rated): 50/60 Hz ± 3 Hz
Power consumption (rated): 100 VA
Output conditions
Output voltage (rated): DC 24 V ± 5%
Output current (rated): 2.0 A
Output power (rated): 48 VA
Peak output current: 4.5 A
Unit specifi-
cation
Dimensions
(H x W x D)
68 x 136 x 32 mm {2.68 × 5.35 × 1.26"} (excluding projections)
Weight Approximately 0.4 kg {14.11 oz} (excluding AC cables)
Color Black (matte)
136
68
32
(Unit: mm)
