Chapter 1 Product Overview
1
Product Overview
This chapter describes the features and specifications of this product.
Product Overview
This is a customer display capable of displaying kanji characters. By using an installation option, it can be
attached to a system or installed on a countertop.
Features
The DM-D500 has the following features.
Display
• Dot matrix display with 256 columns x 64 lines. It allows for multi-colored expressions with kanji characters,
shop logo and so on.
Kanji character: 16 columns x 4 lines (character size of 16x16 dots)
Alphanumeric character: 32 columns x 4 lines (when character size is 8x16 dots)
• Vacuum fluorescent display. It allows for wide viewing angle and good legibility in both well-lit and dark
locations.
In addition, the vacuum fluorescent display has a long life. (Avoid continuously turning on the same dot for
long periods of time as it may cause luminance degradation)
• Green display color with adjustable brightness.
• NV memory to store and display graphics.
Installation
• When attached to the optional DP-501 (dedicated stand), it can be installed stand-alone on a countertop.
• By using the optional DP-502 (DM-D pole unit for TM printers), it can be attached to a TM printer.
(For details, see "Connecting a TM Printer and Option" on page 18)
Installed on a countertop using the
optional DP-501 (dedicated stand)
Attached to a TM printer using the optional
DP-502 (DM-D pole unit for TM printers)
