Epson DM-D500 - Installing the Customer Display; Attaching to DP-501

30
Installing the Customer Display
Attaching to DP-501
Attach DM-D500 to DP-501.
Required items
Prepare the required items from among the following, depending on the connection pattern to use. For longer
poles, use the extension support (DP-105). These are all sold separately.
<Power supply unit (PS-180)>
<AC cable>
Extension support
Hook and loop fasteners
<Extension support (DP-105)>
<DP-501>
Base plate
DM-D stand
Fixing screws for RS-232C
connector
Power extension cable
<Serial cable>
(Two in the case of pass-through connection)
