Submenu Function
Color Temp.
You can adjust the overall tint of the image. The image is tinted
blue when a high value is selected and tinted red when a low value
is selected. Values that can be adjusted depend on the Color
Mode settings.
For
sRGB
g
: From 5000K to 10000K in 10 steps
For other settings: From -3 to 6 in 10 steps
Color Adjust-
ment
(This item cannot be selected if Color Mode is set to sRGB
g
.)
You can adjust the color strength for Red, Green, and Blue
individually.
Auto Iris
(This item can be set only if Color Mode is set to Dynamic or
Theatre.)
Set to Normal or High Speed to adjust the iris to obtain the
optimum light for images being projected. Select High Speed to
make faster iris corrections to match the speed of the scene.
The setting is stored for each Color Mode.
s
"Setting Auto Iris" p.54
Reset
You can reset all adjustment values for the Image menu to their
default settings. See the following to return all menu items to
their default settings.
s "Reset Menu" p.135
Signal Menu
Settable items vary depending on the image signal and source currently
being projected. Setting details are saved for each image signal.
You cannot make settings on the Signal menu when the source is USB
Display, USB, or LAN.
s "Automatically Detect Input Signals and Change the Projected Image
(Source Search)" p.43
Submenu Function
Auto Setup
(Only available when analog RGB computer signals are being
input.)
Set to On to automatically adjust Tracking, Sync., and Position to
the optimum state when the input signal changes.
Resolution
(Only available when analog RGB computer signals are being
input.)
Set to Auto to automatically identify the resolution of the input
signal. If images are not projected correctly when set to Auto, for
example if some of the image is missing, adjust to Wide for wide
screens, or set to Normal for 4:3 or 5:4 screens depending on the
connected computer.
List of Functions
117

Table of Contents

Other manuals for Epson EB-535W

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-535W and is the answer not in the manual?

Epson EB-535W Specifications

General IconGeneral
Number of colors1.07 billion colors
Native aspect ratio16:10
Projection distance0.5 - 1.2 m
Vertical scan range50 - 85 Hz
Projection technology3LCD
Supported aspect ratios-
Contrast ratio (typical)16000:1
Screen size compatibility53 - 116 \
Projector native resolutionWXGA (1280x800)
Keystone correction, horizontal-15 - 15 °
Projector brightness (economic mode)1900 ANSI lumens
FocusManual
Throw ratio0.48 - 0.65:1
Focal length range6.4 mm
Lamp power215 W
Light source typeLamp
Service life of light source5000 h
Service life of light source (economic mode)10000 h
Full HDNo
HD-ReadyYes
Video processing10 bit
Analog signal format systemNTSC, NTSC 4.43
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantity2
VGA (D-Sub) ports quantity3
Ethernet LAN data rates10, 100 Mbit/s
Noise level37 dB
Country of originChina
Noise level (economic mode)29 dB
RMS rated power16 W
PlacementDesktop
Product typeShort throw projector
Product colorWhite, Grey
Market positioningPresentation
Cable lock slot typeKensington
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.28 W
Power consumption (typical)298 W
Power consumption (PowerSave)221 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, VGA
Bundled softwareiProjection, Epson Projector Management
Pallet weight0 g
Quantity per pack1 pc(s)
Quantity per pallet40 pc(s)
Quantity per pallet (UK)60 pc(s)
Quantity per pallet layer4 pc(s)
Harmonized System (HS) code85286200
Quantity per pallet layer (UK)6 pc(s)
USB display function3 in 1: Image / Mouse / Sound
Sustainability certificatesTCO
Weight and Dimensions IconWeight and Dimensions
Depth315 mm
Width344 mm
Height94 mm
Weight3700 g
Package depth497 mm
Package width386 mm
Package height215 mm
Package weight5860 g
