Correcting Automatically (EB-536Wi only)
Auto V-Keystone
When the projector detects any movement, for example when it is installed,
moved, or tilted, it automatically corrects vertical keystone distortion. This
function is called Auto V-Keystone.
When the projector remains still for about two seconds after it detects
movement, it displays a screen for adjustment and then automatically
corrects the projected image.
You can use Auto V-Keystone to correct the projected image under the
following conditions.
Correction angle: approx. 7˚ up and down
a
Auto V-Keystone works only when Projection is set to Front from
the Configuration menu.
s Extended - Projection p.120
If you do not want to enable Auto V-Keystone, set Auto V-
Keystone to Off.
s Settings - Keystone - H/V-Keystone - Auto V-Keystone
p.119
If the projector is moved slightly, motions may not be detected and
Auto V-Keystone may not be performed.
Adjusting the Image Size
Press the [Wide] and [Tele] buttons on the control panel to adjust the size
of the projected image.
a
You can also make adjustments from the Configuration menu.
s Settings - Zoom p.119
Adjusting the Image Position
Press the foot adjust lever to extend the front adjustable foot.
a
The larger the angle of tilt, the harder it becomes to focus. Install the
projector so that it only needs to be tilted at a small angle.
Adjusting the Horizontal Tilt
Extend and retract the rear feet to adjust the projector's horizontal tilt.
Adjusting Projected Images
52
