Easy Interactive Function Setting Items (EB-536Wi only)
General
Submenu Function
Auto Calibration
Starts auto calibration.
Manual Calibra-
tion
Starts manual calibration.
Pen Mode
(This can only be set when projecting images from a computer.)
Changes the function for the interactive pen. When set to PC
Free Annotation (default), you can draw on the projected
screen. When set to PC Interactive, you can operate a computer
from the projected screen. You can change the interactive pen
function with the [Pen Mode] button on the remote control, or
the pen mode icon on the projected screen.
Hovering
When set to On (default), the pointer follows the pen tip as you
hover it over the screen and move it around.
Submenu Function
Advanced
 Distance of Projectors: When using multiple projectors in the
same room, adjust the interactive pen operations according to
the distance between the projectors. If interactive pen
operations are unstable, try another mode. The standard
distance set for Mode 1 is 2 m.
 Sync of Projectors: When using multiple projectors in the
same room, select the method for controlling the interactive
pen interference. When set to Infrared (default), only infrared
is used to synchronize. Set to Wired when connecting the
projectors using cables.
s "Connecting Multiple Projectors (EB-536Wi only)"
p.38
 Wired Sync Mode: When set to Mode 1 (default), only cable
connections are used to synchronize. When set to Mode 2, and
Sync of Projectors is set to Wired, infrared synchronization is
also performed at the same time. Set to Mode 2 when using in
the same room as projectors that do not support cable
connections.
 Confirm Clear Screen: When set to On (default), a
confirmation screen is displayed before clearing all of the
content drawn on the projected screen.
 Color Palette: When set to Palette 2, it changes to a color
palette suitable for people who are color blind. Try Palette 2 if
you find it hard to see the default color palette.
List of Functions
123

Epson EB-535W Specifications

General

Number of colors	1.07 billion colors
Native aspect ratio	16:10
Projection distance	0.5 - 1.2 m
Vertical scan range	50 - 85 Hz
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	16000:1
Screen size compatibility	53 - 116 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-15 - 15 °
Projector brightness (economic mode)	1900 ANSI lumens
Focus	Manual
Throw ratio	0.48 - 0.65:1
Focal length range	6.4 mm
Lamp power	215 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
HD-Ready	Yes
Video processing	10 bit
Analog signal format system	NTSC, NTSC 4.43
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	3
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	37 dB
Country of origin	China
Noise level (economic mode)	29 dB
RMS rated power	16 W
Placement	Desktop
Product type	Short throw projector
Product color	White, Grey
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.28 W
Power consumption (typical)	298 W
Power consumption (PowerSave)	221 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, VGA
Bundled software	iProjection, Epson Projector Management
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	60 pc(s)
Quantity per pallet layer	4 pc(s)
Harmonized System (HS) code	85286200
Quantity per pallet layer (UK)	6 pc(s)
USB display function	3 in 1: Image / Mouse / Sound
Sustainability certificates	TCO

Weight and Dimensions

Depth	315 mm
Width	344 mm
Height	94 mm
Weight	3700 g
Package depth	497 mm
Package width	386 mm
Package height	215 mm
Package weight	5860 g
